Pigment menekşe 23-Corimax Menekşe RLS

Pigment violet 23 is an organic compound that is a commercial pigment. It is member of the dioxazine family of heterocyclic compounds, but derived from carbazoles. It is prepared by condensation of chloranil and 3-amino-N-ethylcarbazole. It has a centrosymmetric angular structure. For many years, the structure was assigned, incorrectly, as having a "linear structure" (EC no. 228-767-9, CAS RN 6358-30-1) which differ in terms of the carbazole ring fusion.

Pigment violet 23 is prepared by condensation of an aniline with chloranil.[From Wiki]

Pigment violet 23 teknik parametreleri

Renk İndeksi No.	Pigment menekşe 23
Ürün adı	Corimax Violet RLS
Ürün Kategorisi	Organik pigment
Işık Haslığı (kaplama)	7
Isı Dayanımı (kaplama)	200
Işık Haslığı (plastik)	7
Isı Dayanımı (plastik)	250
Renk
Ton dağılımı

Zeyachem is a global supplier of Dioxazine Violet pigments that provide a bluish violet shade, a color not obtainable by other pigments.

The extremely high color strength of Pigment violet 23 makes it a suitable pigment as a shading component. PV23 also exhibits excellent heat fastness and light fastness properties, making it suitable for inks and many paints and coatings applications.

Corimax Violet RLS is a reddish blue shade Dioxazine Violet (PV23) pigment with very high color strength and excellent overall fastness properties, suitable for inks, paints and coatings, including industrial coatings, powder coatings and automotive coatings.

Özellikleri:

low viscosity, high gloss, high color strength. Pigment Violet 23 is a transparent purple violet pigment with high saturation and tinting strength.

C.I.Pigment Violet 23 show good tinting strength in flexible PVC while poor resistance to immigration.

P.V.23 heat resistance above 230℃ in polyolefins, when used in transparent PS, temperature shall below 220℃, above this PV 23 shall decompose. When worked in polyester, it is 280℃ stable in 5 hours, while concentration shall above 0.05%.

The pigment is easy to use and requires no rinsing. To ensure maximum color intensity and proper adhesion to the pulp, a retention agent must be added to the pulp before the pigment is applied. Our pigments are supplied by volume sizes. The actual weight varies, depending upon the density of the pigment.

Uygulama:

Otomotiv boyaları, mimari boyalar, rulo boyalar, endüstriyel boyalar, toz boyalar, baskı pastaları, PVC, kauçuk, PS, PP, PE, PU, ofset mürekkepler, su bazlı mürekkepler, solvent mürekkepler, UV mürekkepleri için önerilir.

Pigment Violet 23 (PV 23) has now been around for more than 55 years. Its beginnings go back to 1928, when a patent was filed for the pigment after researchers at the Hoechst company in Germany first undertook the multistage synthesis based on carbazole, an ingredient of coaltar, and chloranile. Until the end of World War II the pigment was only used to process diamine light blue, a direct dyestuff for cotton.

With the invention of reactive dyes, which considerably simplified the dyeing and printing process for cellulose fibers, this application lost its importance. A new and promising use for PV 23 was quickly found due to the pigment’s ability to produce unique colors.

PV 23 has been used as a pigment since 1953. PV 23 belongs to the group of high-performance polycyclic pigments (HPP’s) that are used whenever the requirements for a colorant are particularly high. These include high light fastness and weather fastness, fastness to solvents, and heat stability. In addition, PV 23 stands out by its high coloring power. Under the electron microscope, the crude violet shows a highly granular crystalline form, whereas the pigment particles are miniscule.
-------------------------------------------------- ---------------

İlgili bilgi

Fiziksel ve kimyasal özellikler:
Ton veya ışık: mavi mor
Bağıl yoğunluk: 1.40-1.60
Yığın yoğunluğu / (lb / gal): 11.7-13.3
Erime noktası / ℃: 430-455
Ortalama parçacık boyutu / μm: 0.04-0.07
Parçacık şekli: kübik / çubuk
Spesifik yüzey alanı / (m2 / g): 45-102
pH değeri / (% 10 bulamaç): 6.2

Ürün kullanımı:Pigment menekşe 23, esas olarak kaplamaların, mürekkeplerin, lastiklerin ve plastiklerin renklendirilmesinde ve ayrıca sentetik liflerin renklendirilmesinde kullanılır.
Pigmentin 124 çeşit ticari formülasyon markası vardır. Karbazoazin, güçlü ve olağandışı bir uygulama ile bir tür mavi menekşe çeşididir ve monolit menekşe RN'nin spesifik yüzey alanı 74m2 / g'dir. Kaplama, mürekkep baskı, plastik ve kumaş baskı ve boyama gibi çeşitli alanlarda yaygın olarak kullanılmaktadır. Renklendirme sırasında vernikleme iyi haslığa sahiptir. Hava kurutma boyası, otomobil boya OEM ve fırın boyası için, özellikle CuPc tonerli lateks boya ve güçlü ışık tonu için kullanılabilir. Poliolefin içinde 280 heat ısı direnci ve yüksek renk retansiyonu ile plastik renklendirme için kullanılabilir (1 / 3SD'li HDPE için pigment konsantrasyonunun sadece% 0.07'si gereklidir); ayrıca polyester ve PE Renklendirme için kullanılabilir.

Sentez prensibi: Karbazol hammadde olarak kullanılır ve N-etilasyon, bir faz ters çevirme katalizörü varlığında normal basınç altında gerçekleştirilir ve bir nitrasyon reaksiyonu ve bir indirgeme reaksiyonu, 2-amino-N-etilkarbazolün sentezlenmesi için gerçekleştirilir; 3,5,6-tetrakloroparakinon (Chloranil), yoğuşma ve halka kapama reaksiyonlarına tabi tutulur, süzülür, su ile yıkanır ve ham bir karbazol menekşesi elde etmek üzere kurutulur; son olarak, CI pigment menekşe 23 elde etmek için yoğurma veya yoğurma ile genel pigmentasyon tedavisi.

takma adları:Pigment Violet RL; 51319; C.I. Pigment Violet 23; 8,18-Dichloro-5,15-diethyl-5,15-dihydrodiindolo(3,2-b:3',2'-m)tri- phenodioxazine; CI 51319; Diindolo(3,2-b:3',2'-m-)triphenodioxazine, 8,18-dichloro-5,15-diethyl-5,15-dihydro-; Carbazole Dioxazine Violet; Carbazole Violet; Chromofine Violet RE; Cyanadur Violet; Dioxazine Violet; Dioxazine purple; EB Violet 4B7906; EMC Violet RL 10; Fastogen Super Violet RN; Fastogen Super Violet RN-S; Fastogen Super Violet RTS; Fastogen Super Violet RVS; Helio Fast Violet BN; Heliofast Red Violet EE; Heliogen Violet; Heliogen Violet R Toner; Hostaperm Violet RL; Hostaperm Violet RL Special; Hostaperm Violet RL Special 14-4007; Lake Fast Violet RL; Lake Fast Violet RLB; Lionogen Violet R 6100; Lionogen Violet RL; Lionol Violet HR; Monolite Fast Violet R; PV Fast Violet BL; PV Fast Violet RL-SPE; Paliogen Violet 5890; Paliogen Violet L 5890; Permanent Violet; Permanent Violet R; Sandorin Violet BL; Sanyo Permanent Violet BL-D 422; Sumikacoat Fast Violet RSB; Sumitone Fast Violet RL; Sumitone Fast Violet RL 4R; Sumitone Fast Violet RLS; Symuler Fast Violet BBL; Symuler Fast Violet BBLN; Unisperse Violet B-E; Vynamon Violet 2B; 8,18-Dichloro-5,15-diethyl-5,15-dihydrodiindolo(3,2-b:3',2'-m)triphenodioxazine; Diindolo(3,2-b:3',2'-m)triphenodioxazine, 8,18-dichloro-5,15-diethyl-5,15-dihydro-; 8,18-dichloro-5,15-diethyl-5,15-dihydrocarbazolo[3',2':5,6][1,4]oxazino[2,3-b]indolo[2,3-i] phenoxazine

Moleküler yapı:
